FF-K20

MODEL		VOLTAGE		NO LOAD		AT MAXIMUM EFFICIENCY					STALL
		OPERATING	NOMINAL	SPEED	CURRENT	SPEED	CURRENT	TORQUE		OUTPUT	TORQUE		CURRENT
		RANGE	V	r/min	A	r/min	A	mNm	g.cm	W	mNm	g.cm	A
FF-K20VA	06205	2.0-3.5	3	11800	0.04	5800	0.1	0.147	1.5	0.07	0.27	2.8	0.16
FF-K20VA	07130	2.0-4.0	3.5	23800	0.04	18700	0.15	0.12	1.25	0.25	0.57	5.82	0.56
