BO motor offset shape 3v 13.8mm 60RPM L Shaped Single Shaft dc Spur Gear Motor for Smart car robot
OUTLINE DRAWING： Unit:mm
GEAR BOX LENGTH (L) WEIGHT:~11.5g
| Gear box length L (mm) |
General Reduction Ratios | ||||||||||||
| 13.8 | 1/48 | 1/87 | - | - | - | - | - | - | - | ||||
| 1/120 | 1/180 | - | - | - | - | - | - | - | |||||
| 1/220 | 1/288 | - | - | - | - | - | - | - | |||||
TECHNICAL DATAS:
| Ratio | Model No. | Voltage | No Load | On Load | Stall Torque | |||||||||||
| Operating Range |
Nominal Voltage |
Current | Speed | Current | Torque | Speed | Torque | Current | ||||||||
| V | V | A | r/min | A | kg.cm | r/min | kg.cm | A | ||||||||
| Bo motor-18100-220 | 3.0-12.0 | 3 | 0.2 | 50 | 0.6 | 1.233 | 40 | 4 | 2.15 | |||||||
| Bo motor-14175-120 | 3.0-12.0 | 3 | 0.16 | 60 | 0.3 | 0.362 | 52 | 1 | 0.87 | |||||||
| Bo motor-14150-120 | 3.0-12.0 | 3 | 0.16 | 65 | 0.3 | 0.362 | 52 | 2.055 | 0.87 | |||||||
| Besides, 100rpm, 150rpm, 200rpm, 300rpm BO motors are very popular.We can also provide wheels. | ||||||||||||||||
